Equipment Specs

Manufacturer Pilatus
Model PC-12 NGX
Max. Occupants 9
Max. Cruise Speed 290 KTAS
Max. Range 1,803 nm
Max. Operating Altitude 30,000 ft
Wingspan 53 ft 4 in
Max Aircraft Length 47 ft 3 in
Max Tail Height 14 ft 0 in

Album 1

Interior of Pilatus PC 12 NGX aircraft showing cabin seating | Pilatus for SaleInterior cabin of Pilatus PC 12 NGX aircraft showing pull out table and seatPilatus PC 12 NGX AvionicsExterior of a Pilatus PC-12 aircraft, view 1

Planes for Sale

Are you considering purchasing a PC-12 NGX? Our expertise as a private jet broker can help you through every step of the process, from research to acquisition, CFS Jets is here to help you!

Contact Us

Phone number:


704.359.0007

Email:


sales@cfsjets.com

We are open:


Monday – Friday 9 AM – 5 PM

download brochure contact cfs jets view inventory view all services
Additional Specifications
Cost Summary

These numbers are derived assuming 200 annual hours and a fuel price of $6.04 / GAL

Average Pre-Owned Price
$4,700,000
Annual Budget
$528,719
Variable Cost
$938/hr

FUEL (GAL): 77 gal/hr
FUEL COST: $349
MAINTENANCE: $278
ENGINE RESERVES: $232
CREW & MISCELLANEOUS: $79

Fixed Cost
$247,319

CREW EXPENSE: $99,840
CREW TRAINING: $15,900
AIRCRAFT MODERNIZATION: $35,700
HANGAR: $34,500
INSURANCE: $44,487
AIRCRAFT MISCELLANEOUS: $16,892

Standard Avionics
  • Garmin G3000 Avionics Package w/ Synthetic Vision
  • EFIS- GDU-1400 3-Tube 14-Inch
  • AHRS: Dual Garmin-77
  • Weather Radar: Garmin GWX-70
  • NAVS: Dual Garmin GIA-63W
  • Radar Altimeter: Collins ALT-4000
  • FMS: Dual Garmin GTC-570 w/WAAS GPS & Flight ID
  • HF: Honeywell HF-9000 (Provisions Only)
  • ADF: Garmin
  • DME: Collins DME-4000
  • TRANS: Dual GTX-3000 Mode S w/ Diversity (ADS-B)
  • SATCOM: Garmin Iridium GSR-56
  • SATPHONE: Aircell Iridium
  • TAWS: Garmin EGPWS Class B
  • TCAS: Garmin GTC-8000 TCAS II
Interior

Internal Dimensions:

  • Length: 16 ft 11 in (5.16 m)
  • Width: 5 ft 0 in (1.52 m)
  • Height: 4 ft 10 in (1.47 m)

Color Options:

Bisque, French Roast, Glacier, Jet Black, Silver Mirage, Toffee

Features:

LED Lighting Throughout, Refreshment Center or Side-Facing Seat, Adjustable Club Seats, Primary Seats Come Standard with Access to An Executive Table, Fourteen Large Windows, Standard Belted Lavatory

Exterior

External Dimensions:

  • Wingspan of 53 ft 4 in (16.28 m)
  • Max Aircraft Length of 47 ft 3 in (14.40 m)
  • Max Tail Height of 14 ft 0 in (4.26 m)

Weights:

  • Max Takeoff Weight of 10,495 lb (4,760 kg)
  • Basic Operating Weight of 8,540 lbs (3,874 kg)
  • Useful Load of 5,530 lbs (2,508 kg)

The Pilatus PC-12 NGX is considered the greatest single-engine aircraft in the world. Built for safety and value, this aircraft outshines other Pilatus models, even those in the PC-12 series. With low operating costs and high performance, owners get the most from their investment when they purchase the Pilatus PC-12 NGX.

With a take-off distance of 2,485 ft, a range of 1,803 nm, and maximum cruise speeds of 290 KTAS, the PC-12 NGX can navigate short, rough terrain with ease. This Pilatus model also rules when it comes to safety with over seven million flight hours of safe and smooth operation and advanced safety details including advanced situational awareness features. In addition to its impressive technological features, this aircraft has 10 luxury passenger seating options.

Pilatus Aircraft LTD is the manufacturer of this world-class aircraft model. Founded in 1939, Pilatus contributes to the past, present, and future of aviation with a range of reputable models including the Pilatus PC-12 NGX, PC-24, PC-7, PC-21, and many more! Learn more about other aircraft from Pilatus, such as the Pilatus PC-12/47 and Pilatus PC-24.
